There is a 98 Dakota at a pick n pull near my house that has everything. Could I take the complete package (just splice in the wiring harness connector from the 98 XJ gas tank) and the ohms and psi match what a 98 XJ setup would be?

Was finally done with interior paintish. I never really prepped it properly. But the primer is super good. I also left the primer out to sit for 2 weeks waiting for color. But I think the cab will be fine. Anyway… I started sound proofing and putting small interior bits on.

I have never seen this bit of information on any forum. But, the 97+ door wiring harness does not fit into the oval shaped hole in the 88 MJ. It is approximately 1/2” too short and 1/8” too skinny. Secondly the door jam switches have too small of holes. The pass through for the wiring harness is 3/4” on the 98 donor. 1/2” hole for the switch itself. The MJ has both holes too small. As illustrated in the the second picture. The drilled out hole on the top is the size you need. The one below is the stock 88 MJ size.

Here it is after 2 or 3 coats of color and 1 coat of clear coat from Mastercoat. It’s called AG111. Really good stuff.

I had a quart of basecoat in the factory color of Dark Baltic Metallic. Well…. It started out good. I had started out in the cab with a light tac coat of color. I soon realized after taking pictures and oogling? the color that I wasn’t going to have enough. So then I didn’t take many pictures of the process while painting after that because I tried to prioritize the places I needed the most paint. The engine bay and frame. I knew to reorder paint it’d be at least a week and the primer would be cured by then. So I colored the heck out of the engine bay knowing I just really wanted a nice engine bay. I left a bunch of spots unpainted. The next weekend after I painted some trim pieces since I didn’t have the color yet.

Primed the truck with Mastercoat Silver consisting if 3 coats of I remember correctly. It was a complete mess in the garage. I did nearly zero prep of the truck. Didn’t cover a lot of stuff in the garage. So a considerable amount of things in the garage got silver dots all over them. Not my brightest or fun moment. Oh well we move.

Sorry the photos look horrible on my phone they look decent.* I had a 6 week timeline to finish the swap and get her running under her own power. I got delayed 2 weeks with all the perfectionist fab work. So this weekend I said I can’t get all the rust and I can’t make sure I thought about every step ahead so I don’t have to back track. So I had some friends come over and help weld the frame stiffeners. quite the gap… Some rust and bent steel from my first time pulling a motor. Fixed up the hood latch. It sits below where the MJ one would sit. I ALSO THINK I FOUND THE LEAK THAT CAUSED MY RUSTY FLOOR PANS!!

I last left off with pulling the 4.0 and throwing the 44 in the rear. I did a ton more fab work. Including patching various unnecessary holes made by the previous owner, plating the front of the frame/unibody(the Dirtbound frame stiffeners aren’t the best fit but I got them cheap), fixed the steering column hole in the firewall, and other various things. I also accidentally cut a hole in the front of the frame cutting off some frame stiffeners for a steering brace I’ll pick up soon. I did fix it however. 16 gauge sheet metal for a frame. I took the 4.0 to a local Jeep mechanic to get it refreshed. It looked really good on the inside so I’m hoping the camshaft, rings, bearing, or whatever he said he’s gonna do to it works out. Idk I’m not knowledgeable on motors. Getting there was one of the sketchiest things I’ve done in a while with a vehicle. For the 97+ swap I had to find a spot for the AW4 shift cable. Thankfully I mocked up the wiring harness to see if there was enough room under the tcu harness pass through. Annnnnd just barely does it sit flush so I know I won’t have a leak. Found that a random plastic push fender liner holder thingy had its own dedicated hole through the floor pan wildly enough. I didn’t like that so I patched it with the welder since I want zero leaks in this if I can try for it. here the steering column fitment issue I had. I freehanded this hole with a carbide bit on a die grinder since I wanted to save the donor firewall in case of an emergency. I didn’t want to mess up donor firewall by putting it in wonky and not lining up. But I corrected the hole so happy. Then had a friend mock up the cemetery console from the 98 donor and the hole for the washer fluid bottle.

Sorry everyone I thought I had replied but I must have not hit submit but… I have yet to open the diff up. It’s really stuck on there good. I’ll try to prioritize that once I get to the axles. I’m not sure how to do the pinion angle setup. So that’s my reasoning with going with what it had when I got it. I know for a fact that at least that works. haha I wish too. My dad is now retired and in Athens, Greece at his wife’s family’s villa for half the year. Oh to have nothing to do but fish the Mediterranean. I bet your son will love your help. At 27 my dad did help me drop the transmission from the donor and it was one the best memories I’ll ever have moving forward with the project. However, a week later he left with his fishing poles in his luggage.

thanks! Pulled the engine and getting it ready for the local jeep mechanic to look it over. I then mocked up the front end for some motivation. I guess it worked a little because I got the rear XJ Dana 44 back on. It’s a welded differential so I’m positive I won’t keep it. I believe I’m going to just weld on the brackets in the correct position for the 8.25 from my donor 98 and see about a stock ride height. 8.5” is a lot of lift. I got the driver door off the donor. Which was a task since it’s parked up near a fence on the driver side. I mocked it up to get an idea as to where the door latch mod needs to be placed.

Been a while but I got most of the welding on the interior of the cab. I’ll have to get some more pictures of the welded pieces. I don’t have have them all. I was able to spray the Mastercoat silver primer with my 3m accuspray gun. I then used 3 spray cans of the factory paint to put the basecoat. I thought it was going to take 1 can but… 2-1/2 cans and I barely was able to put down one good coat. Then I topped it off with the Mastercoat AG11 in clear.

Woah that’s something I’ve never seen before or even knew existed.

I was able to prep and weld in the left dash mount Friday. I used Mastercoat silver underneath where the mounting bracket would sit. I sanded the paint off where the spot welds would be.

Got the right side dash mounting post welded in. Did a fit up test on the dash this past weekend. Doing a lot this weekend. Will post more of the dash modification from 97+ donor XJ when I’m not outside in 110°F+ heat.

Mastercoat is like a super primer. It's mainly used as a primer for chassis undercoat. It is pretty much POR-15 but way better. But, yeah it should be clean metal. So, I'll probably end up using just the epoxy primer.
