Ctwilson1

Would you happen to know if they got an O2 sensor or not based on that picture? I just thought about it while I’m at work

Well I have no updates in regards to the gauge cluster. We moved and I’m starting a new job plus my masters program started back up so I’ve been busy! Finally got around to bringing the truck down to the new place to find out someone cut the catalytic converter 👎 made for a awfully loud drive and is definitely discouraging. But the good news is the truck has a garage!!!!

I’m hopefully going to work on it tomorrow so I’ll double check some things first and then give that a shot. Thanks for the heads up!

Sounds like a super power if you ask me

What about the cleaner gauge cluster being all the way empty? and I can’t confirm but I’m 99.9% certain that the fuel gauge on the dirty one didn’t move at all when I plugged it into the truck and started it

The fuel gauge on the 3/4 looks just like the one I currently have with the dummy lights? Or do you mean the circuitry in the back?

I really don’t think so, because when I went to verify the plug was still working with the dummy-light gauges it was fine and I made sure to keep the orientation

Very true. Will definitely be checking the fuses when I get to working on the truck this weekend.

And here are pics of the gauge cluster I bought from another forum user

This would be the gauge cluster out of the ‘87 XJ Pioneer. Sorry the cover is pretty hazy but you have top left: coolant temp bottom left: ??? top right: oil pressure bottom right: voltage

that is a valid point, I should check that, but I think because the stock cluster is working (Atleast the fuel gauge is), I would assume that fuse is good

I’ve been trying to take a multimeter to the back of the gauge cluster but I’ve got no clue what I’m looking for

I plug either of the new to me clusters in and get absolutely nothing when I key on to accessory or when I start the Jeep. No movement of the gauges at all

The one I pulled looks as good as the current one (no corrosion) but the one I got from someone on here is much worse off.. I might get around to linking pics when I get off work

I know the one from the junkyard was out of an 87 (it’s got the big fuel gauge but also has temp & voltage) and then the one from here I’m not sure about but it’s got everything (RPM, small fuel gauge, temp, voltage, oil pressure). and my truck is an 89
